Specifications
Model CS-H6c-R105-1L3WF
Camera
Image Sensor 1/2.7" Progressive Scan CMOS
Shutter Speed Self-adaptive shutter
Lens 4mm @ F1.6, viewing angle: 82° (Horizontal), 48° (Vertical), 98° (Diagonal)
Lens Mount M12
Day & Night IR-cut filter with auto-switching
DNR 3D DNR
WDR Digital WDR
Compression
Video Compression H.264/H.265
Video Bit Rate Adaptive bit rate.
Max. Resolution 2304 × 1296
Frame Rate Self-Adaptive during network transmission
Network
Smart Alarm Motion Detection, Human Shape Detection, Loud Noise Detection
Wi-Fi Pairing AP paring
Protocol EZVIZ Cloud Proprietary Protocol
Interface Protocol EZVIZ Cloud Proprietary Protocol
Interface
Storage Supports microSD card (Up to 512 G)
Power TYPE-C
Wired Network RJ45 X 1 (10M/100M self-adaptive Ethernet port)
Wi-Fi
Standard IEEE802.11b, 802.11g, 802.11n
Frequency Range 2.4 GHz ~ 2.4835 GHz
Channel Bandwidth Supports 20MHz
Security WPA/WPA2, WPA-PSK/WPA2-PSK
Transmission Rate 11b: 11Mbps, 11g :54Mbps, 11n :72Mbps
Output Power(EIRP) 19 dBm
Antenna Gain 1.9 dBi
